Generous 8″ × 14″ Embroidery Area

The spacious embroidery area is ideal for sizable projects, including large home décor and jacket backs — all without rehooping.

Over 1,200 Built-In Embroidery Designs

Explore the embroidery design library featuring over 1,200 designs, 50 fonts, and one 3D puff embroidery font. Access additional designs via the Artspira Mobile App or create your own using the built-in My Design Center.

Built-In Camera Feature (InnovEye®)

Allows you to get a real-time camera view of the needle and fabric. Virtually preview your design on fabric for precise placement down to the exact stitch before you begin stitching.

Wireless Enabled

The PR1060W is designed with wireless capabilities, offering a highly flexible, connected, and streamlined user experience. Transfer designs wirelessly without cables or USB drives.

Mobile App Connectivity

The My Stitch Monitor App alerts you when it’s time to change threads or when your project is complete. The Artspira Mobile App allows access to embroidery, printing, and cutting designs — and you can customize your own embroidery patterns by drawing directly on your mobile device.

Matrix Copy Feature

The Matrix Copy feature allows you to add multiple copies of the same design to your project. It automatically places repeat designs for maximum efficiency — waste less fabric and time, and create multiple patches in one hooping.

Security Lock & Key Optimization

Security Lock Modes can manage multiple users for businesses without requiring multiple passwords and logins. The Key Optimization System allows a business owner to customize access to machine functions for different roles. A Shortcut Key lets the user jump directly to the embroidery screen from multiple screens to save time.

My Design Center

Brother’s exclusive My Design Center offers built-in design capabilities — all without a PC. Features include custom draw, inside and outside auto stippling, and fill patterns.

10-Needle Speed — Industry-Leading Acceleration

Get productive with fast embroidery speeds up to 1,000 stitches per minute, reached in just seven seconds with industry-leading high-speed acceleration. Speeds are adjustable per needle, down to 400 SPM for specialty threads or cap and cylinder frames.

10.1″ HD LCD Touchscreen

See designs on the large 10.1″ built-in high-definition IPS LCD display. Scroll through menus, navigate crystal-clear icons, and see your design properties in preview mode. Supports pinch-to-zoom and drag-and-drop editing. Brightness auto-adjusts.

Optional Embroidery Software

The optional BE EmbroideryStudio Software includes a CorelDRAW® plugin and a comprehensive set of embroidery digitizing tools. The optional PE-DESIGN 11 software lets you link as many as 10 machines wirelessly for scalable production.

Built-In Tutorial Video Library

View 33 high-definition tutorial videos covering basic operations through advanced embroidery functions, accessible via QR code on your mobile device. Most users can be up and running in as little as 90 minutes.

Key Specifications

• Needle Count: 10
• Maximum Embroidery Area: 8″ × 14″ (200 × 360 mm)
• Maximum Embroidery Speed: 1,000 stitches per minute (variable 400–1,000 SPM)
• Acceleration: Reaches 1,000 SPM in 7 seconds
• Built-In Designs: Over 1,200 embroidery designs
• Built-In Fonts: 50 fonts, including 1 exclusive 3D puff embroidery font
• Display: 10.1″ high-definition IPS LCD touchscreen (pinch-to-zoom, drag-and-drop)
• Camera: Built-in InnovEye® camera for real-time needle view and virtual design preview
• Connectivity: Wireless (Wi-Fi); compatible with Artspira and My Stitch Monitor apps
• Thread Cutter: Upper and lower automatic thread trimmers
• Security: Security Lock Modes; Key Optimization System for multi-user businesses
• Tutorial Videos: 33 built-in HD tutorials accessible via QR code
• Languages: 16 built-in languages
• Voltage: 120V / 60Hz
